Generic Mobile Phone Board and Industrial Module Item GSM/CDMA Fixed Wireless Terminals

low cost Sagem RL300 GSM dialer/gsm fwtSagem RL300 GSM fixed cellular terminal/gsm fwt-RL300 Fixed GSM Gateway

RL300 is a convenient GSM gateway used to connet phone to access GSM net

140,83 €

7 Items

Quantity
Price
5
133,79 €
10
126,75 €
20
112,67 €
50
105,63 €
100
98,58 €
200
91,54 €
500
84,50 €
1000
77,46 €

RL300

Description


low cost Sagem RL300 GSM dialer/gsm fwtSagem RL300 GSM fixed cellular terminal/gsm fwt-RL300 Fixed GSM Gateway

RL300 is a convenient GSM gateway used to connet phone to access GSM network plugging your phone on the device will allow you don areas with a lack of PSTN lines, it is a rapid and economical solution to deploy rapidly new subscriber lines.

Furthermore, in all the countries, it is an interesting solution for mobile operators to increase the use of their GSM network by offering fixed services additionally to mobile services.

The SAGEM RL300 supports additionally to standard voice communications, SMS service. It provides access to GSM supplementary services and GSM voice mail server.

Basic installation of SAGEM RL300 is very simple and can be performed by the subscriber himself: he has just to plug the power supply in a mains socket and switch
on the phone.

Furthermore it can be personalized according to the requirements of the different operators.

SAGEM RL300 fixed gsm gateway is a convenient GSM gateway used to connect phone to access GSM network plugging your phone on the device will allow you to:
-send and receive voice calls,
-send and receive SMS*
-Interrogate your voicemail

SMS
RL300 supports SMS sending and receiving.*please check your phone manual to check if it supported and usage instructions
Service center configuration:
Number: 0172 227 0333
In order to activate the SMS service you need first to send a SMS to your own number, if failures occur , SMS service will be deactivated. Sending successfully a SMS will reactivate it.

Call
Make or receive a call is Similar to your fixed line
When your phone is ringing just lift up the handset of the telephone set and speak.
Dial your number, after a timeout (end of dialing timeout default value:4sec)the call Will be launched. To speed up you can press# at the end of the number.
To handle a second call, press r2, to accept, swap between calls.
To join the 2 calls and make a multiparty call, press r3
If voicemail led is blinking, call the 5500 to listen to your messages.
During the call the led will be switched off.


TECHNICAL FEATURES
GSM

Frequency bands:

Two double band versions:

- TDMA 850 / PCS 1900

- EGSM 900 / DCS 1800

Transmit power:

Class 4 (2W) for TDMA850 / EGSM900

Class 1 (1W) for DCS1800 / PCS1900

SIM card:

Support of 3 V mini SIM cards

Security features

Sim lock

SERVICES

Voice:

DTMF dialing

All codec supported

- AMR, EFR, FR and HR

Supplementary services, incl. CLIP

Emergency calls

Call waiting / call holdcalls history

Multiparty

SMS:

Sending and receiving

Fixed line SMS protocol
STATUS INDICATIONS

RF received level

Power status

Voicemail received, etc...

CONFIGURATION OF THE PHONE

Factory settings

DTMF programming

USER INTERFACES

Power supply

RJ11 connector

SIM card push/push mechanism

RJ11 adapter (optional)

EXTERNAL POWER SUPPLY

AC input: 100 - 240 VAC; 50 - 60 Hz

Mains plug: EU or US

DIMENSIONS & WEIGHT (APPROX.)

195 mm x 151 mm x 38 mm

200 grams without charger

ENVIRONMENT

Operating temperature: 0 to 55

Humidity: 10% to 70% (non condensing)

CERTIFICATION

Fully CE certified
R&TTE, GCF, WEEE
