Lighting autonomous radar motion detector, battery ST323 Closet, Room
It is a new type of light sensor to save energy. Its performance is stable and reliable. When one enters the detection area and triggers the lamp is lit.
Starting the lamp will turn off automatically
Function:
Can identify day and night: the default setting for this period is less than 20LUX LUX, it can not be worked in this environment, such as dusk or at night, in the daytime, and it will stop working in the AUTO position .
The delay time is continuously added: When it receives the second signal after the first induction induction, it will calculate the time again on the rest of the first base timer (set time).
Installation and Test:
Select a location where you want to install this light, nail screws.
Insert 4 x 1.5 V AA batteries into the battery compartment;
Check the right figure with the position of the point .. Slide the switch to "ON", the LED is always on without detection function,.
Slide the switch to "OFF", the lamp is off;
Slide the switch to "AUTO", the sensor is activated. The lamp lights up when motion is detected, when the illumination of the environment is less than 20LUX. The lamp turns off automatically about 30 seconds later, after the last detected movement.
Note: When testing this article, keep the lighting below 20LUX environment (at dusk), otherwise light sensor does not work!
Some problem solving
The lamp does not work
a. check if the battery power is sufficient;
b. whether ambient light work is in accordance with the instruction
The sensitivity is low
a. check in front of the detection window if nothing can affect signal reception
b. check if the detection signal is in the detection range;
c. check if the temperature is too high.
d. check the mounting height.
e. check if the orientation is correct in motion.
The sensor can not automatically turn off the lamp:
a. check whether a detection signal y 'continuous
b. check the battery connections
c. check the temperature near the sensor. Such as air conditioning,
