copy of 3.6v 2700mAh lithium battery Li-er14505 scl02 LS14500 ls14500c lst14500 er6s-tc er6 er6c er6lv tl5903

Electrical Characteristic ER14505 is LiSOCI2 battery and it is non-rechargeable!
Battery Model: ER14505
Battery Size: AA
Dimension ?14.5*50.5mm
Nominal Voltage 3.6V
Cut off voltage 2.0V(at 1mA discharge)
(At 1.0mA, +25°C 2.0V cut off. The capacity restored by the cell varies according to current drain, temperature and cut-off,For more severe conditions,consult ACCX.)
Operating temperature range

-60~+85°C
(Operating at different temperature may reduce the capacity and lower the voltage )
Storage(recommended) Max. 30°C
Max. recommended continuous current 100mA
Max. pulse current 200mA
Typical weight Max. 20g
Self life >10 years
Self discharge current less than 1 % per year
Key features

1. High and stable operating voltage
2. Low self discharge rate(less than 1% after 1 year of storage at +25°C)
3. Stainless steel container
4. Hermetic glass-to-metal sealing
5. Non-flammable electrolyte
6. Bobbin type
7. UL,UN, CE,SGS recognized
Main applications

1. Utility metering
2. Memory back-up
3. Alarms and security devices
4. Automotive electronics
5. Tollgate systems
6. Military electronics
7. Automatic meter reading
8. professional electronics

Warning

1. Fire, explosion and severe burn hazard.
2. Do not recharge, crush, disassemble, heat above 100°C;
3. Do not solder directly to the cell.
