220V 4KW Single Phase input and 220V 3 Phase Output Frequency Converter / Adjustable Speed Drive / Frequency Inverter / VFD

220v 4kw single phase input and 220v 3 phase output frequency converter/adjustable speed drive/frequency inverter/VFD

1.Output Power: 4kw
2.Rated Frequency :50hz/60hz
3.Output Frequency Range:0~650Hz
4.Input Voltage Range:single phase (1 phase) 220V±15%
5.Output Voltage Range:3 phase 220V±15%
6.Control way: Open loop vector control(SVC) V/F control
7.Main function: Control and adjust the speed of the ac motor
8.Size: 130*160*170mm

small size, low temperature up, low noise, reliable performance, is a new generation of V/F high-performance universal frequency inverter. Brings high torque, high accuracy, high reliability, wide range speed drive, what makes motor work with high efficiency.

Product features:
1 Small size, simple operation.
2..Built-in parameter auto-tuning function,can automatically identify the characteristic of motor and set up related parameter, make the motor run continualy steadily even when the operating parameter of motor changes as times go by .
3.Protection function in all fields: protection of under-voltage, over-voltage, over-current, prevention of motor stall, over-load and over-heat.
4.Standard V/F mode, Noninductive vector mode, Output power(torque) contol mode.
5.Control function special for industrial mechanic:6 kinds of multifunction programmable digital input function
6.The range of output frequency is 0.00~650.00Hz.
7.Adopts low inductance structure, reduce the peak voltage of circuit, strengthen the EMC function, improve the reliability of product greatly.
